Product Information For InRouter302 LTE CAT 4 Router
InRouter302 Specifications
| HARDWARE PLATFORM | |
|---|---|
| CPU Platform | 580MHz |
| RAM | 128MB DDR2 |
| Flash | 32MB SPI |
| INTERFACE | |
| Ethernet Port | 2* 10/100Mbps Fast Ethernet |
| Serial Port | IR301: 1 RS-232 & 1 RS-485, IR302: None |
| Power Supply | DC 9–36V |
| Reset Button | Pinhole reset |
| SIM Card | Dual 2FF SIM |
| Wi-Fi (Optional) | IEEE 802.11 b/g/n, 150Mbps |
| Antenna Connector | SMA & RP-SMA (varies by model) |
| MECHANICAL SPECS | |
| Dimensions (mm) | 90 x 90 x 25 |
| Weight | 240g |
| Installation Method | Panel / Rail mounting |
| Housing | Metal, IP30 |
| Cooling | Fanless |
| POWER RATE | |
| Working Power | 200–220mA @12V |
| Standby Power | 240mA @12V |
| Peak Power | 90–120mA @12V |
| ENVIRONMENT | |
| Operating Temp | -20 ~ 70℃ |
| Storage Temp | -40 ~ 85℃ |
| Humidity | 5 ~ 95% (non-condensing) |
| CERTIFICATIONS | |
| Compliance | CE, FCC, PTCRB, IC, Verizon, AT&T |
Free Delivery Info
Free delivery on orders over R750 to all major cities. No hidden fees.
Local Delivery (Johannesburg, Cape Town and Surrounds)
| Order Value / Weight | Rate (ZAR) |
|---|---|
| R750 or more | Free |
| R750 or less (0–2kg) | R60 |
| R750 or less (2–5kg) | R90 |
| R750 or less (5–10kg) | R90 |
| Bulky Items (15kg+) | R250 |
Main Centres (JHB, DBN, PTA, CPT, BFN, PE, EL)
| Order Value / Weight | Rate (ZAR) |
|---|---|
| R750 or more | Free |
| R750 or less (0–2kg) | R90 |
| R750 or less (2–5kg) | R90 |
| R750 or less (5–10kg) | R150 |
| Bulky Items (15kg+) | R350 |
Regional Delivery
| Weight | Rate (ZAR) |
|---|---|
| 0–2kg | R120 |
| 2–5kg | R150 |
| 5–10kg | R220 |
| 15kg+ | R450 |
Courier & Delivery Times
Preferred couriers: The Courier Guy, Courier IT, and Dawn Wing.
Standard delivery: 3–5 business days nationwide.
Need it faster? Contact us directly. Express orders must be placed before 10am for same-day dispatch.
Note: Remote area rates available on request. Email sales@boltontechnical.co.za.
We reserve the right to amend delivery fees. All updates will be reflected here.
Returns & Refunds
2-Year Warranty
All our signal boosters and cellular amplifiers include a 2-year limited manufacturer’s warranty. If your unit experiences a fault during this period, please reach out to us — we’ll assess the issue and, where applicable, arrange for repair or replacement. Our goal is to support you well beyond your initial purchase, within reasonable use and warranty terms.
30-Day Return Policy
We understand that circumstances can change. That’s why we offer a 30-day return period for most products, subject to inspection and approval. While we strive to make this process smooth, returns are handled on a case-by-case basis to ensure fairness for both parties.
To request a return, please call us at (JHB) 011-749-3085 or CPT 021 879 3057 or email sales@boltontechnical.co.za to obtain an RMA (Return Merchandise Authorisation) number before sending anything back.
Return Conditions
- Items must be unmodified, in original condition, and include all accessories.
- Original packaging and proof of purchase are required.
- Returns that are not in original condition and packaging may be subject to a handling fee.
- The warranty does not cover damage due to misuse, mishandling, or unauthorised modifications.
- Customers are responsible for return shipping. We’ll cover the shipping cost back to you if a repair or replacement is approved.
- Products purchased on promotion or clearance can only be returned within 5 days of receipt.
- Express shipping fees are non-refundable.
Product Dimensions
